KBM系列无框直驱电机

采用了最新直接驱动技术的KBM系列无框直驱电机凭借多种的规格和转矩,为当今设计工程师们提供所需的高性能、长寿命和便捷安装。选配的封闭数字式霍尔效应传感器经过预先调整并安装有增长的轴向转子,以实现适当的触发。 不同的绝缘选择可实现在广泛的线路输入电压下工作。 请参见我们提供的选型手册和在线选型指南,以查看可用的各种预设选件和配置。
作为优化解决方案专家,我们也提供包括特殊绕组配置、定制安装功能、直径和叠片长度调整、材料变化、绝缘类型、磁回路优化等定制解决方案,以满足您应用的独特需求。

相关产品
AKD 系列伺服驱动器

科尔摩根 AKD™ 系列组成了完善而齐备的基于以太网的伺服驱动器系列产品,该系列产品运行速度快...

特点

  • 完全密封的定子绕组
  • 155C 内部绕组温度持续能力
  • PTC 热敏电阻 (雪崩式) 过载保护
  • 稀土钕铁硼磁体
  • 转子磁体的自动防故障频带,兼容RoHS
  • UL, CE认证
  • 可定制的转子轮毂尺寸

优势

  • 和负载直接连接,消除了减速机、同步带和滑轮
  • 零齿隙提供了更好的系统性能
  • 消除了机器连接设备,降低了机器的整体尺寸
  • 内置式电机使机器更为紧凑
  • 大量的标准电机备选,并提供定制化服务,助您更快,更经济的研发您的机器
KBM(S)机框尺寸 外径 通空直径 连续失速转矩 峰值失速转矩 额定输出功率
KBM(S)-10 59.96 mm
(2.95 in)
16.01 mm
(.63 in)
.49 - 1.45 Nm 1.17 - 4.91 Nm 0.9 - 3.0 KW
KBM(S)-14 74.9 6mm
(2.95 in)
20.01 mm
(.79 in)
1.22 - 2.92 Nm 3.28 - 10.50 Nm 0.9 - 3.0 KW
KBM(S)-17 84.96 mm
(3.34 in)
30.01 mm
(1.18 in)
2.06 - 6.20 Nm 5.95 - 24.00 Nm 0.9 - 3.0 KW
KBM(S)-25 109.96 mm
(4.33 in)
50.01 mm
(1.97 in)
4.85 - 11.1 Nm 14.4 - 54.8 Nm 0.9 - 3.0 KW
KBM(S)-35 139.96 mm
(5.51 in)
65.01 mm
(2.56 in)
12.4 - 25.9 Nm 40.8 - 93.0 Nm 0.9 - 3.0 KW
KBM(S)-45 189.96 mm
(7.48 in)
85.02 mm
(3.35 in)
29.7 - 54.6 Nm 119 - 218 Nm 0.9 - 3.0 KW
KBM(S)-43 159.78 mm
(6.29 in)
76.28 mm
(3.00 in)
6.11 - 44.2 Nm 18.0 - 153 Nm 0.9 - 3.0 KW
KBM(S)-57 202.90 mm
(7.99 in)
104.17 mm
(4.10 in)
18.8 - 109 Nm 60 - 441 Nm 0.9 - 3.0 KW
KBM(S)-60 229.85 mm
(9.05 in)
105.05 mm
(4.14 in)
29.4 - 154 Nm 69.1 - 393 Nm 8.4 - 20.1 KW
KBM(S)-79 259.63 mm
(10.22 in)
152.43 mm
(6.00 in)
43.5 - 222 Nm 152 - 1075 Nm 8.4 - 20.1 KW
KBM(S)-88 331.46 mm
(13.05 in)
155.01 mm
(6.10 in)
102 - 545 Nm 197 - 1200 Nm 8.4 - 20.1 KW
KBM(S)-118 361.11 mm
(14.22 in)
225.04 mm
(8.86 in)
172 - 672 Nm 498 - 2400 Nm 8.4 - 20.1 KW
KBM(S)-163 605.0 mm
(23.82 in)
315.50 mm
(12.42 in)
764 - 1329 Nm 1966 - 3932 Nm 8.4 - 20.1 KW
KBM(S)-260 850.0 mm
(33.46 in)
557.85 mm
(21.96 in)
1932 - 3445 Nm 6494 - 12812 Nm 8.4 - 20.1 KW
